5 mm LDR

Features:

• Diameter: 5mm
• No. of Pins: 2
• Type of Mounting: PCB Through Hole
• Maximum Operating Temperature: +800C (Approx.)
• Dark resistance:1-20M ohm

Specifications:

• Maximum Voltage (V-dc): 150V
•  Maximum Power Consumption (mW): 100W
•  Temperature (°C): –30 – +70
•  Spectrum Peak Value (nm): 540 OD
•  Bright Resistance (10Lux) (KΩ): < 45
•  Dark Resistance (MΩ): > 200
•  Light resistance: < 8 k
•  Dark resistance: > 20 megohm
•  100¦Ë10: 0.6
•  Response Time (ms): Up: 20/ Down: 30
•  Light Resistance Characteristic: 3
•  The length of the pins: > 2.5 CM/0.98″
•  Material: Carbon
•  Performance: General
•  Shape: cylindrical
•  Size: 5 x 3mm/0.2 x 0.12″

• Camera Exposure control
• Auto slide focus – dual cell
• Photocopy machines – density of toner
• Colorimetric Test Equipment
• Densitometer
• Electronics scales – dual cell
• Automatic gain control – modulated light source
• Automated Rear View Mirror

Digital Applications:

• Automatic Headlight Dimmer
• Nightlight control
• Oil burner flame out
• Streetlight control
• Absence / Presence (Beam breaker)
• Position sensor
