Double BTS7960B DC 43A H-bridge Stepper Motor Driver

SKU: A000194

Apple Shopping Event

Hurry and get discounts on all Apple devices up to 20%

Sale_coupon_15

 1,800

20 in stock

20 in stock

16 People watching this product now!
  • Pick up from the MA Robotic

To pick up today

Free

  • TCS Courier delivery

Our courier will deliver to the specified address

All Over Pakistan

2-3 Days

Description

The Double BTS7960 43A H-Bridge High-Power Stepper Motor Driver Module is; a fully integrated high current H bridge for motor drive applications using the BTS7960 high current half-bridge. the BTS7960 is part of the NovalithICTM family. This contains one p-channel high side MOSFET and one n-channel low side MOSFET; with an integrated driver IC in one package. Due to the p-channel high side switch; the need for a charge pump is eliminated thus minimizing EMI.

Interfacing to a microcontroller is made easy by the integrated driver IC which features logic level inputs; diagnosis with current sense, slew rate adjustment; dead time generation and protection against over-temperature, over-voltage, under-voltage; overcurrent, and short circuit.

The Double BTS7960 43A H-Bridge High-Power Stepper Motor Driver Module provides; a cost-optimized solution for protected high current PWM motor drives with very low board space consumption.

Specifications:

  • Input voltage(V) : 6 – 27
  • Maximum current(A) : 43
  • Input level(V) : 3.3 – 5
  • Duty cycle : 0 – 100%
  • Path resistance : 16 mΩ at 25°C.
  • Low quiescent current : 7 µA at 25°C
  • Operating Frequency(kHz) : 25

Features:

  • PWM capability of up to 25 kHz combined with active freewheeling.
  • Switched-mode current limitation for reduced power dissipation in overcurrent.
  • Status flag diagnosis with current sense capability.
  • Overtemperature shut down with latch behavior.
  • Overvoltage lockout.
  • Undervoltage shut down.
  • Driver circuit with logic level inputs.
  • Adjustable slew rates for optimized EMI.
  • 74AHC244 Schmitt-trigger Octal buffer/line driver for ESD protection (Inputs accept voltages higher than VCC).

Input Ports:

  • RPWM: forward level or PWM signal input, active high.
  • LPWM: Reverse level or PWM signal input, active high.
  • R_EN: forward drive enable input, high-level enable, low level off.
  • L_EN: Reverse drive enable input, high-level enable, low level off.
  • R_IS: forward drive current alarm output.
  • L_IS: Reverse drive current alarm output.
  • VCC: +5 V power output, 5V power supply connection with the microcontroller.
  • GND: signal common low end.
