The DS18B20 digital temperature sensor is a highly accurate and versatile device designed to measure temperature with precision. Its compact size, robust construction, and easy-to-use interface make it an ideal choice for various applications, ranging from industrial monitoring systems to home automation projects.

Specifications of DS18B20 Digital Temperature Sensor:

• Temperature Range: -55°C to +125°C
• Temperature Measurement Accuracy: ±0.5°C within the range of -10°C to +85°C
• Resolution: Programmable from 9 to 12 bits
• Digital Output: One-wire interface Unique 64-bit Serial Code for each sensor
• Parasite Power Mode: Can operate without an external power source, drawing power from the data line
• Operating Current: Typical 1mA during temperature conversion
• Waterproof Variants: Available with a stainless steel waterproof probe
• Cable Length: Supports up to 100 meters between sensors and the controller
• Compatibility: Compatible with various microcontrollers, such as Arduino and Raspberry Pi
• Supported Libraries: Wide range of software libraries and code examples available for easy integration
• Dimensions: Compact size for easy installation
• Application Examples: Industrial monitoring systems, home automation projects, environmental monitoring, weather stations, HVAC systems, and more
• Power Supply: 3.0V to 5.5V operating voltage range
• Package Type: TO-92, 8-pin SOIC, or waterproof stainless steel probe
• RoHS Compliance: Meets RoHS environmental standards
