Mach3 Breakout Board 5 Axes For CNC

SKU: A000246

Apple Shopping Event

Hurry and get discounts on all Apple devices up to 20%

Sale_coupon_15

Original price was: ₨ 1,600.Current price is: ₨ 1,500.

40 in stock

40 in stock

20 People watching this product now!
  • Pick up from the MA Robotic

To pick up today

Free

  • TCS Courier delivery

Our courier will deliver to the specified address

All Over Pakistan

2-3 Days

Description

  1. Mach3 CNC Breakout Board Card 5 Axis One-way relay output port can control the spindle switch with Parallel Port With out Cable in Pakistan.

    1. Fully support for MACH3 and other computer software that supports parallel port control.
    2. USB power supply and peripheral power supply are separated to ensure computer security.
    3. 12-24V wide peripheral voltage input, with anti-reverse connection function.
    4. All input signals are isolated by optical coupling, and can be connected to emergency stop, tool setting, limit, etc.
    5. One-way relay output port can control the spindle switch. The output port is P17 port.
    6. One-way optocoupler isolated 0-10V analog voltage output can control the inverter with the corresponding analog interface to control the spindle speed. The output port is the P1 port.
    7. Open all 17 ports, can be connected with optocoupler drive, can control 5-axis stepper motor.
    8. P1 acts as a PWM output and can control the spindle governor with optocoupler input.
    9. Can be connect to the common cathode/anode drive with input level of 5V.

.
