PL2303 PL2303HX USB To TTL(Serial) Converter Module – 5 Pin

The PL2303 PL2303HX USB To TTL(Serial) Converter Module is adopted imported controller RS232 TTL, which can stabilize the flash with a high-speed 500mA self-recovery fuse for protection. Two data transmission indicators can monitor data transfer status in real-time. Reserve 3.3V and 5V pin interface, easy for DDWRT of different voltage system that needs power.

This PL2303 USB To Rs232 TTL Converter Adapter provides the best and convenient way to connect your rs232 ttl devices or demo board to your pc via the usb port. The entire board is coated by a high-quality transparent heat-shrinkable sleeve, making the PCB in insulation state from outside, so that the board won’t be burnt down by a material shortcut.

Specifications and Features:

• Input Supply voltage (V) : 3.3 ~ 5
• Model: PL2303HX
• Support: Windows 98 to Windows 7 (32 bit and 64 bit) Mac OS 8 to OS X (32 bit and 64 bit) Linux
• Adopt imported controller PL2303HX, which can stabilize the flash with high speed
• 500mA self-recovery fuse for protection.
• Two data transmission indicators can monitor data transfer status in real-time.
• Reserve 3.3V and 5V pin interface, easy for the DDWRT of different voltage system that needs power.
• The entire board is coated by the high-quality transparent heat-shrinkable sleeve, making the PCB in an insulation state from the outside.
• so that the board won’t be burnt down by material shortcuts.
• The electrostatic package ensures the board will not be damaged before use.
• Support the WIN7 system.

Applications:

• All kinds of satellite set-top box upgrades.
• Router, HDD, ADSL, broadband modem firmware upgrade, or cracked upgrade.
• Cellphone, XBOX360, GPS serial communication, vehicle inspection and test, DVD flash, and so on.
• Burn writes STC MCU, NXP MCU, Renesas MCU, NEC MCU, and so on.
• Simple UART communication commonly used UART debugging tools in the supper terminal.
• USB signal transferred to the TTL signal may be used by electronic enthusiasts.
