4-Channel 5v Relay Module

This is a 5V 4-channel relay interface board, and each channel needs a 15-20mA driver current. This 4-way relay module can be used to control various appliances and equipment with large current. This four-channel relay module is equipped with high-current relays that work under AC250V 10A or DC30V 10A. 5 volts relay driver module has a standard interface that can be controlled directly by the microcontroller. This relay module board allows a wide range of microcontrollers such as Arduino, AVR, PIC, ARM with digital outputs to control larger loads and devices like AC or DC Motors, electromagnets, solenoids, and incandescent light bulbs.

Specifications Of 4 Channel DC 5V Relay Module Board For Arduino Raspberry Pi:

• Output Controllable: Digital
• Compatible: With any 5V microcontroller such as Arduino.
• Rated Through-current: 10A (NO) 5A (NC)
• Control Signal: TTL level
• Max. Switching Voltage: 250VAC/30VDC
• Max. Switching Current: 10A
